AC BLOWER 12131

https://www.luft.es/web/image/product.template/60/image_1920?unique=d92ff14

Size:
121 x 121 x 31( 4.76" x 4.76" x1.22")

Construction:
Spriral housing of fiberglass reinforced polycarbonate. Shaded pole motor. Only lead wire. Precise ball bearing or sleeve bearing system.

Operating Temperature:
Sleeve bearing -10ºC to +70ºC
Ball bearing -20ºC to +80ºC

Insulation resistance:
10 meg Ohms min. at 500V DC
(between frame and terminal)

Dielectric strength:
1500 VAC one minute

Weight:
260 grams

0.00 € 0.0 EUR 0.00 €

0.00 €

Not Available For Sale

This combination does not exist.

Contact Us





​​


Model No.BearingRated voltage(VAC)Frequency (Hz)Max.Rated current (mA)Max.input power (W)Speed (r.p.m.)Max. Air Flow (CFM)Max. Air Pressure (mmH2O)Noise dB(A)
KLE115AP120BSWHSleeve11550/60240/21020.0/18.42574/294020/2212.08/13.3046/49
KLE115AP120BBWHBall11550/60240/21020.0/18.42574/294020/2212.08/13.3046/49
KLE230AP120BSWHSleeve23050/60130/11018/.8/17.02600/294020/229.10/10.0046/48
KLE230AP120BBWHBall23050/60130/11018.8/17.02600/294020/229.10/10.0046/48
Model No.BearingRated voltage(VAC)Frequency (Hz)Max.Rated current (mA)Max.input power (W)Speed (r.p.m.)Max. Air Flow (CFM)Max. Air Pressure (mmH2O)Noise dB(A)
KLE115AP120BSWHSleeve11550/60240/21020.0/18.42574/294020/2212.08/13.3046/49
KLE115AP120BBWHBall11550/60240/21020.0/18.42574/294020/2212.08/13.3046/49
KLE230AP120BSWHSleeve23050/60130/11018/.8/17.02600/294020/229.10/10.0046/48
KLE230AP120BBWHBall23050/60130/11018.8/17.02600/294020/229.10/10.0046/48
